TXC CORPORATION
臺灣TXC晶振是一家領先的專業頻率控制產品制造商,致力于雙列直插式封裝(DIP)和表面貼裝器件(SMD)石英晶體和振蕩器產品的研究、設計、制造和銷售.
TXC 晶技晶振目前專注于以下類別的TXC晶振產品:
晶體(32.768KHz、基本 MHz、高精度 MHz、汽車級)
振蕩器(32.768KHz、CMOS、硅 MEMS、差分輸出、SAW、汽車級)
VCXO(CMOS、差分輸出)
TCXO(基本、GPS、精密)
OCXO (CMOS)臺灣TXC晶振,晶技石英晶振,TXC CORPORATION
TXC CORPORATION
is a leading professional frequency control product manufacturer devoted to the research, design, manufacture, and sale of Dual-Inline-Package (DIP) and Surface Mount Device (SMD) quartz crystal and oscillator products.
TXC currently specializes in these TXC晶體categories of products:
Crystals (32.768KHz, Basic MHz, High Accuracy MHz, Automotive Grade)
Oscillators (32.768KHz, CMOS, Silicon MEMS, Differential Output, SAW, Automotive Grade)
VCXO (CMOS, Differential Output)
TCXO (Basic, GPS, Precision)
OCXO (CMOS)臺灣TXC晶振,晶技石英晶振,TXC CORPORATION
TXC晶振料號編碼 | 制造商 | 系列 | 晶振頻率 | 頻率容差 | 負載電容 | 工作溫度 | 腳位 | 尺寸 | 描述 |
7M-12.000MAAJ-T | TXC | 7M | 12 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 12.0000MHZ 18PF SMD |
7M-24.000MAAJ-T | TXC | 7M | 24 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 24.0000MHZ 18PF SMD |
7M-25.000MAAJ-T | TXC | 7M | 25 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 25.0000MHZ 18PF SMD |
7M-10.000MAHE-T | TXC | 7M | 10 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 10.0000MHZ 12PF SMD |
7M-27.000MAAJ-T | TXC | 7M | 27 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 27.0000MHZ 18PF SMD |
7M-25.000MEEQ-T | TXC | 7M | 25 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 25.0000MHZ 10PF SMD |
7M-27.120MEEQ-T | TXC | 7M | 27.12 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 27.1200MHZ 10PF SMD |
7M-27.000MEEQ-T | TXC | 7M | 27 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 27.0000MHZ 10PF SMD |
7M-24.000MEEQ-T | TXC | 7M | 24 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 24.0000MHZ 10PF SMD |
7M-12.000MEEQ-T | TXC | 7M | 12 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 12.0000MHZ 10PF SMD |
7M-16.384MEEQ-T | TXC | 7M | 16.384 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 16.3840MHZ 10PF SMD |
7M-16.000MAAE-T | TXC | 7M | 16 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 16.0000MHZ 12PF SMD |
7M-12.000MAAE-T | TXC | 7M | 12 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 12.0000MHZ 12PF SMD |
7M-50.000MAHV-T | TXC | 7M | 50 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 50.0000MHZ 8PF SMD |
7M-25.000MAHV-T | TXC | 7M | 25 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 25.0000MHZ 8PF SMD |
7M-16.000MAAJ-T | TXC | 7M | 16 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 16.0000MHZ 18PF SMD |
7M-27.120MAAJ-T | TXC | 7M | 27.12 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 27.1200MHZ 18PF SMD |
7M-10.000MAAJ-T | TXC | 7M | 10 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 10.0000MHZ 18PF SMD |
7M-16.000MAHE-T | TXC | 7M | 16 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 16.0000MHZ 12PF SMD |
7M-12.000MAHE-T | TXC | 7M | 12 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 12.0000MHZ 12PF SMD |
7M-48.000MAAJ-T | TXC | 7M | 48 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 48.0000MHZ 18PF SMD |
7M-16.000MEEQ-T | TXC | 7M | 16 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 16.0000MHZ 10PF SMD |
7M-26.000MEEQ-T | TXC | 7M | 26 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 26.0000MHZ 10PF SMD |
7M-30.000MEEQ-T | TXC | 7M | 30 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 30.0000MHZ 10PF SMD |
7M54072001 | TXC | 7M | 54 MHz | ±20ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 54.0000MHZ 8PF SMD |
7M48072001 | TXC | 7M | 48 MHz | ±20ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 48.0000MHZ 8PF SMD |
7M50072001 | TXC | 7M | 50 MHz | ±7ppm | 9pF | -40°C ~ 105°C | 4 | 3225 | CRYSTAL 50.0000MHZ 9PF SMD |
7M-30.000MAAE-T | TXC | 7M | 30 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 30.0000MHZ 12PF SMD |
7M-24.000MAAE-T | TXC | 7M | 24 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 24.0000MHZ 12PF SMD |
7M-26.000MAAE-T | TXC | 7M | 26 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 26.0000MHZ 12PF SMD |
7M-27.000MAAE-T | TXC | 7M | 27 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 27.0000MHZ 12PF SMD |
7M-32.000MAAE-T | TXC | 7M | 32 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 32.0000MHZ 12PF SMD |
7M-48.000MAHV-T | TXC | 7M | 48 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 48.0000MHZ 8PF SMD |
7M-27.120MAHV-T | TXC | 7M | 27.12 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 27.1200MHZ 8PF SMD |
7M-26.000MAAJ-T | TXC | 7M | 26 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 26.0000MHZ 18PF SMD |
7M-32.000MAHE-T | TXC | 7M | 32 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 32.0000MHZ 12PF SMD |
7M-20.000MAAJ-T | TXC | 7M | 20 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 20.0000MHZ 18PF SMD |
7M-27.120MAHE-T | TXC | 7M | 27.12 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 27.1200MHZ 12PF SMD |
7M-36.000MAAJ-T | TXC | 7M | 36 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 36.0000MHZ 18PF SMD |
7M-13.560MAAJ-T | TXC | 7M | 13.56 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 13.5600MHZ 18PF SMD |
7M-20.000MAHE-T | TXC | 7M | 20 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 20.0000MHZ 12PF SMD |
7M-32.000MEEQ-T | TXC | 7M | 32 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 32.0000MHZ 10PF SMD |
7M-38.400MEEQ-T | TXC | 7M | 38.4 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 38.4000MHZ 10PF SMD |
7M54072002貼片晶振 | TXC | 7M | 54 MHz | ±12ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 54.0000MHZ 8PF SMD |
7M-48.000MEEQ-T | TXC | 7M | 48 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 48.0000MHZ 10PF SMD |
7M-13.560MAAE-T | TXC | 7M | 13.56 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 13.5600MHZ 12PF SMD |
7M-50.000MAAE-T | TXC | 7M | 50 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 50.0000MHZ 12PF SMD |
7M-30.000MAHV-T | TXC | 7M | 30 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 30.0000MHZ 8PF SMD |
7M40070041 | TXC | 7M | 40 MHz | ±20ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 40MHZ 12PF SMD |
7M-28.63636MAHE-T | TXC | 7M | 28.63636 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 28.63636MHZ 12PF SMD |
7M48072002 | TXC | 7M | 48 MHz | ±10ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 48.0000MHZ 8PF SMD |
7M-27.000MAHV-T | TXC | 7M | 27 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 27.0000MHZ 8PF SMD |
7M13500011 | TXC | 7M | 13.56 MHz | ±20ppm | 16pF | -20°C ~ 75°C | 4 | 3225 | CRYSTAL 13.5600MHZ 16PF SMD |
7M-25.000MAHE-T | TXC | 7M | 25 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 25.0000MHZ 12PF SMD |
7M-25.000MAAE-T | TXC | 7M | 25 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 25.0000MHZ 12PF SMD |
7M-20.000MBBK-T | TXC | 7M | 20 MHz | ±50ppm | 20pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 20.0000MHZ 20PF SMD |
7M-31.250MAAE-T | TXC | 7M | 31.25 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 31.2500MHZ 12PF SMD |
7M-28.63636MAAE-T | TXC | 7M | 28.63636 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 28.63636MHZ 12PF SMD |
7M-27.120MAAE-T | TXC | 7M | 27.12 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 27.1200MHZ 12PF SMD |
7M-41.000MAAE-T | TXC | 7M | 41 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 41.0000MHZ 12PF SMD |
7M-24.000MAHV-T | TXC | 7M | 24 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 24.0000MHZ 8PF SMD |
7M-10.000MAHV-T | TXC | 7M | 10 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 10.0000MHZ 8PF SMD |
7M-32.000MAHV-T | TXC | 7M | 32 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 32.0000MHZ 8PF SMD |
7M-16.000MAHV-T | TXC | 7M | 16 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 16.0000MHZ 8PF SMD |
7M-19.200MAHV-T | TXC | 7M | 19.2 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 19.2000MHZ 8PF SMD |
7M-12.000MAHV-T | TXC | 7M | 12 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 12.0000MHZ 8PF SMD |
7M-40.000MAHV-T | TXC | 7M | 40 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 40.0000MHZ 8PF SMD |
7M-20.000MAHV-T | TXC | 7M | 20 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 20.0000MHZ 8PF SMD |
7M50070032 | TXC | 7M | 50 MHz | ±10ppm | 18pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 50MHZ 18PF SMD |
7M-25.000MAKV-T | TXC | 7M | 25 MHz | ±30ppm | 8pF | -40°C ~ 125°C | 4 | 3225 | CRYSTAL 25.0000MHZ 8PF SMD |
7M-26.000MAKV-T | TXC | 7M | 26 MHz | ±30ppm | 8pF | -40°C ~ 125°C | 4 | 3225 | CRYSTAL 26.0000MHZ 8PF SMD |
7M-40.000MAKV-T | TXC | 7M | 40 MHz | ±30ppm | 8pF | -40°C ~ 125°C | 4 | 3225 | CRYSTAL 40.0000MHZ 8PF SMD |
7M-19.200MAAE-T | TXC | 7M | 19.2 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 19.2000MHZ 12PF SMD |
7M-26.000MAHE-T | TXC | 7M | 26 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 26.0000MHZ 12PF SMD |
7M-12.288MAAJ-T | TXC | 7M | 12.288 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 12.2880MHZ 18PF SMD |
7M-27.000MAHE-T | TXC | 7M | 27 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 27.0000MHZ 12PF SMD |
7M-40.000MAAJ-T | TXC | 7M | 40 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 40.0000MHZ 18PF SMD |
7M-37.400MEEJ-T | TXC | 7M | 37.4 MHz | ±10ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 37.4000MHZ 18PF SMD |
7M-50.000MAAJ-T | TXC | 7M | 50 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 50.0000MHZ 18PF SMD |
7M50070021 | TXC | 7M | 50 MHz | ±15ppm | 10pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 50.0000MHZ 10PF SMD |
7M38872001 | TXC | 7M | 38.88 MHz | ±7ppm | 9pF | -40°C ~ 105°C | 4 | 3225 | CRYSTAL 38.8800MHZ 9PF SMD |
7M25072001 | TXC | 7M | 25 MHz | ±7ppm | 9pF | -40°C ~ 105°C | 4 | 3225 | CRYSTAL 25.0000MHZ 9PF SMD |
7M-40.000MEEQ-T | TXC | 7M | 40 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 40.0000MHZ 10PF SMD |
7M-12.288MEEQ-T | TXC | 7M | 12.288 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 12.2880MHZ 10PF SMD |
7M-13.560MEEQ-T | TXC | 7M | 13.56 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 13.5600MHZ 10PF SMD |
7M-19.200MEEQ-T | TXC | 7M | 19.2 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 19.2000MHZ 10PF SMD |
7M-114.285MCFJ-T | TXC | 7M | 114.285 MHz | ±100ppm | 18pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 114.2850MHZ 18PF SMD |
7M-12.288MAAE-T | TXC | 7M | 12.288 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 12.2880MHZ 12PF SMD |
7M-10.000MAAE-T | TXC | 7M | 10 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 10.0000MHZ 12PF SMD |
7M-26.000MAHV-T | TXC | 7M | 26 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 26.0000MHZ 8PF SMD |
7M-24.000MAHE-T | TXC | 7M | 24 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 24.0000MHZ 12PF SMD |
7M-24.576MAAJ-T | TXC | 7M | 24.576 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 24.5760MHZ 18PF SMD |
7M-14.31818MAAJ-T | TXC | 7M | 14.31818 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 14.31818MHZ 18PF SMD |
7M30772001 | TXC | 7M | 30.72 MHz | ±7ppm | 9pF | -40°C ~ 105°C | 4 | 3225 | CRYSTAL 30.7200MHZ 9PF SMD |
7M-22.000MEEQ-T | TXC | 7M | 22 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 22.0000MHZ 10PF SMD |
7M-18.432MEEQ-T | TXC | 7M | 18.432 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 18.4320MHZ 10PF SMD |
7M-38.400MAHV-T | TXC | 7M | 38.4 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 38.4000MHZ 8PF SMD |
7M-20.000MAAE-T | TXC | 7M | 20 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 20.0000MHZ 12PF SMD |
7M-12.288MAHV-T | TXC | 7M | 12.288 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 12.2880MHZ 8PF SMD |
