Silicon晶振Si531 XO利用天空解決方案的先進DSPLL®電路提供一個高頻低抖動時鐘晶體振蕩器。Si531晶振小體積7.0x5.0mm六腳貼片晶振,可提供從10到945MHz的任意速率輸出頻率,并選擇頻率到1400MHz。與傳統的XO不同,每個輸出頻率都需要一個不同的晶體,使用一個固定的晶體來提供一個大范圍的輸出頻率。這種有源晶振基于集成電路的方法允許晶體諧振器提供特殊的頻率穩定性和可靠性。此外,DSPLL時鐘合成提供了優越的電源噪聲抑制,簡化了在通信系統中通常發現的噪聲環境中產生低抖動時鐘的任務。基于Si531 IC的XO可在工廠中進行配置,可用于各種用戶規格,包括頻率、電源電壓、輸出格式和溫度穩定性。特定的配置在裝運時被工廠編程,從而消除了與定制振蕩器相關的長交貨時間。高頻低抖動時鐘振蕩器531AC200M000DG專用于時鐘和數據恢復
原廠代碼 | 品牌 | 型號 | 頻率 | 電壓 | 頻率穩定度 | 包裝/封裝 |
531BB125M000DG | Silicon晶振 | Si531 | 125MHz | 3.3V | ±20ppm | 6-SMD, No Lead |
531FB200M000DG | Silicon晶振 | Si531 | 200MHz | 2.5V | ±20ppm | 6-SMD, No Lead |
531FC250M000DG | Silicon晶振 | Si531 | 250MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FB125M000DG | Silicon晶振 | Si531 | 125MHz | 2.5V | ±20ppm | 6-SMD, No Lead |
531BC000110DG | Silicon晶振 | Si531 | 148.35165MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC200M000DG | Silicon晶振 | Si531 | 200MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC250M000DG | Silicon晶振 | Si531 | 250MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC125M000DG | Silicon晶振 | Si531 | 125MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531FB106M250DG | Silicon晶振 | Si531 | 106.25MHz | 2.5V | ±20ppm | 6-SMD, No Lead |
531AC156M250DG | Silicon晶振 | Si531 | 156.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531AC200M000DG | Silicon晶振 | Si531 | 200MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC148M500DG | Silicon晶振 | Si531 | 148.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC156M250DG | Silicon晶振 | Si531 | 156.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531AC125M000DG | Silicon晶振 | Si531 | 125MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531FC125M000DG | Silicon晶振 | Si531 | 125MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC156M250DG | Silicon晶振 | Si531 | 156.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC148M500DG | Silicon晶振 | Si531 | 148.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531AC155M520DG | Silicon晶振 | Si531 | 155.52MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC155M520DG | Silicon晶振 | Si531 | 155.52MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531FC200M000DG | Silicon晶振 | Si531 | 200MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531AC622M080DG | Silicon晶振 | Si531 | 622.08MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531AC312M500DG | Silicon晶振 | Si531 | 312.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531AC106M250DG | Silicon晶振 | Si531 | 106.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531EC106M250DG | Silicon晶振 | Si531 | 106.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531BC187M500DG | Silicon晶振 | Si531 | 187.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531EC155M520DG | Silicon晶振 | Si531 | 155.52MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531AC187M500DG | Silicon晶振 | Si531 | 187.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531EC187M500DG | Silicon晶振 | Si531 | 187.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531EC000110DG | Silicon晶振 | Si531 | 148.35165MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531EC148M500DG | Silicon晶振 | Si531 | 148.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC155M520DG | Silicon晶振 | Si531 | 155.52MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531EC156M250DG | Silicon晶振 | Si531 | 156.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531AC311M040DG | Silicon晶振 | Si531 | 311.04MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC311M040DG | Silicon晶振 | Si531 | 311.04MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531EC311M040DG | Silicon晶振 | Si531 | 311.04MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531EC622M080DG | Silicon晶振 | Si531 | 622.08MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC622M080DG | Silicon晶振 | Si531 | 622.08MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC311M040DG | Silicon晶振 | Si531 | 311.04MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531BC622M080DG | Silicon晶振 | Si531 | 622.08MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531FC312M500DG | Silicon晶振 | Si531 | 312.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531EC312M500DG | Silicon晶振 | Si531 | 312.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531AC250M000DG | Silicon晶振 | Si531 | 250MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531EC250M000DG | Silicon晶振 | Si531 | 250MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531BC312M500DG | Silicon晶振 | Si531 | 312.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531AA156M250DG | Silicon晶振 | Si531 | 156.25MHz | 3.3V | ±50ppm | 6-SMD, No Lead |
531BC106M250DG | Silicon晶振 | Si531 | 106.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531EC125M000DG | Silicon晶振 | Si531 | 125MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC106M250DG | Silicon晶振 | Si531 | 106.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC187M500DG | Silicon晶振 | Si531 | 187.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC000110DG | Silicon晶振 | Si531 | 148.35165MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531EC200M000DG | Silicon晶振 | Si531 | 200MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531AC000110DG | Silicon晶振 | Si531 | 148.35165MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531AC148M500DG | Silicon晶振 | Si531 | 148.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531AC125M000DGR | Silicon晶振 | Si531 | 125MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC125M000DGR | Silicon晶振 | Si531 | 125MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531EC125M000DGR | Silicon晶振 | Si531 | 125MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC125M000DGR | Silicon晶振 | Si531 | 125MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531AC106M250DGR | Silicon晶振 | Si531 | 106.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC106M250DGR | Silicon晶振 | Si531 | 106.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531EC106M250DGR | Silicon晶振 | Si531 | 106.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC106M250DGR | Silicon晶振 | Si531 | 106.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC25M0000DGR | Silicon晶振 | Si531 | 25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531AC155M520DGR | Silicon晶振 | Si531 | 155.52MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531AC156M250DGR | Silicon晶振 | Si531 | 156.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC155M520DGR | Silicon晶振 | Si531 | 155.52MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC156M250DGR | Silicon晶振 | Si531 | 156.25MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531EC155M520DGR | Silicon晶振 | Si531 | 155.52MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531EC156M250DGR | Silicon晶振 | Si531 | 156.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC155M520DGR | Silicon晶振 | Si531 | 155.52MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC156M250DGR | Silicon晶振 | Si531 | 156.25MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531AC187M500DGR | Silicon晶振 | Si531 | 187.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC187M500DGR | Silicon晶振 | Si531 | 187.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531EC187M500DGR | Silicon晶振 | Si531 | 187.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC187M500DGR | Silicon晶振 | Si531 | 187.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531AC000110DGR | Silicon晶振 | Si531 | 148.35165MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531AC148M500DGR | Silicon晶振 | Si531 | 148.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531AC200M000DGR | 貼片晶振 | Si531 | 200MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC000110DGR | Silicon晶振 | Si531 | 148.35165MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC148M500DGR | Silicon晶振 | Si531 | 148.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC200M000DGR | Silicon晶振 | Si531 | 200MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531EC000110DGR | Silicon晶振 | Si531 | 148.35165MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531EC148M500DGR | Silicon晶振 | Si531 | 148.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531EC200M000DGR | Silicon晶振 | Si531 | 200MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC000110DGR | Silicon晶振 | Si531 | 148.35165MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC148M500DGR | Silicon晶振 | Si531 | 148.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC200M000DGR | Silicon晶振 | Si531 | 200MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531AC312M500DGR | Silicon晶振 | Si531 | 312.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC312M500DGR | Silicon晶振 | Si531 | 312.5MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531EC312M500DGR | Silicon晶振 | Si531 | 312.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC312M500DGR | Silicon晶振 | Si531 | 312.5MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531AC250M000DGR | Silicon晶振 | Si531 | 250MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531AC311M040DGR | Silicon晶振 | Si531 | 311.04MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531AC622M080DGR | Silicon晶振 | Si531 | 622.08MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC250M000DGR | Silicon晶振 | Si531 | 250MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC311M040DGR | Silicon晶振 | Si531 | 311.04MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531BC622M080DGR | Silicon晶振 | Si531 | 622.08MHz | 3.3V | ±7ppm | 6-SMD, No Lead |
531EC250M000DGR | Silicon晶振 | Si531 | 250MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531EC311M040DGR | Silicon晶振 | Si531 | 311.04MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531EC622M080DGR | Silicon晶振 | Si531 | 622.08MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC250M000DGR | Silicon晶振 | Si531 | 250MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC311M040DGR | Silicon晶振 | Si531 | 311.04MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531FC622M080DGR | Silicon晶振 | Si531 | 622.08MHz | 2.5V | ±7ppm | 6-SMD, No Lead |
531AA640M000BG | Silicon晶振 | Si531 | 640MHz | 3.3V | ±50ppm | 6-SMD, No Lead |
Si531晶振特征:
可與任意速率的輸出頻率從10 MHz到945MHz和選擇頻率到1.4 GHz
第三代DSPLL®具有優越的抖動性能
比基于saw的振蕩器好3倍的頻率穩定性
內部固定的晶體頻率確保了高可靠性和低老化
可用的CMOS、LVPECL、LVDS和CML輸出石英晶體振蕩器
3.3、2.5和1.8 V的供應選項
工業標準7.0x5.0mm封裝和針形管
無鉛/符合RoHS標準
應用于:超聲波,網絡系統,SD/高清視頻,測試和測量,時鐘和數據恢復,F(xiàn)PGA/ASIC時鐘生成
