5G無線模塊6G路由器6G模塊與TG-5006CJ愛普生溫補晶振X1G004131001700
展望2022年,中國臺灣工研院產科國際所預估,5G及商用筆記本電腦等市場需求依然強勁,2022年全球半導體產值可望持續成長8.8%.據中國臺灣經濟日?qǐng)?bào)報道指出中國臺灣半導體產業以晶圓代工、封裝測試以及芯片設計的專業分工模式,建構完整產業鏈并研發最先進制程技術,愛普生晶振與全球國際大廠如蘋果、谷歌等廠商進行合作,共同設計、生產具強大計算性能的高端芯片并裝載于最先進的終端應用產品中.帶動全球ICT產業的發展,如蘋果營業額成長達33%,谷歌營業額成長41%.
TG-5006CJ愛普生溫補晶振X1G004131001700,5G無線模塊6G路由器6G模塊晶振
削頂正弦波
削峰正弦波
愛普生有源晶振編碼
型號
頻率
長X寬X高
輸出波
電源電壓
X1G004131000400
TG-5006CJ
26.000000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
1.700to1.900V
Clippedsinewave
X1G004131000600
TG-5006CJ
16.367667MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004131000700
TG-5006CJ
16.368000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004131000800
TG-5006CJ
16.369000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004131000900
TG-5006CJ
19.200000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004131001000
TG-5006CJ
26.000000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004131001100
TG-5006CJ
38.400000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004131001300
TG-5006CJ
16.367667MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004131001400
TG-5006CJ
16.368000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004131001500
TG-5006CJ
16.369000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004131001600
TG-5006CJ
19.200000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004131001700
TG-5006CJ
26.000000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004131001800
TG-5006CJ
38.400000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
1.700to3.300V
Clippedsinewave
X1G004131002600
TG-5006CJ
40.000000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004131002900
TG-5006CJ
19.200000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.600to3.000V
Clippedsinewave
X1G004131003100
TG-5006CJ
40.000000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004131003200
TG-5006CJ
26.635300MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.700to3.465V
Clippedsinewave
X1G004131003300
TG-5006CJ
28.974000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.700to3.465V
Clippedsinewave
X1G004131003400
TG-5006CJ
26.000000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
1.700to1.900V
Clippedsinewave
X1G004131003600
TG-5006CJ
26.000000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.660to2.940V
Clippedsinewave
X1G004131003700
TG-5006CJ
19.200000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.660to2.940V
Clippedsinewave
X1G004131003800
TG-5006CJ
26.000000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
1.700to1.900V
Clippedsinewave
X1G004131004100
TG-5006CJ
40.000000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004131004200
TG-5006CJ
32.000000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004131004400
TG-5006CJ
24.576000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
3.135to3.465V
Clippedsinewave
X1G004131004900
TG-5006CJ
26.000000MHz
2.00x1.60x0.73mm
VC-TCXO~TCXO
1.700to1.900V
Clippedsinewave
X1G004201000600
TG-5006CE
16.367667MHz
3.20x2.50x0.90mm
VC-TCXO~TCXO
1.700to1.900V
Clippedsinewave
X1G004201000800
TG-5006CE
16.369000MHz
3.20x2.50x0.90mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004201000900
TG-5006CE
19.200000MHz
3.20x2.50x0.90mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004201001000
TG-5006CE
26.000000MHz
3.20x2.50x0.90mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004201001300
TG-5006CE
16.367667MHz
3.20x2.50x0.90mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004201001700
TG-5006CE
26.000000MHz
3.20x2.50x0.90mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004201002000
TG-5006CE
26.000000MHz
3.20x2.50x0.90mm
VC-TCXO~TCXO
2.660to2.940V
Clippedsinewave
X1G004201002300
TG-5006CE
26.000000MHz
3.20x2.50x0.90mm
VC-TCXO~TCXO
1.700to3.465V
Clippedsinewave
X1G004201002500
TG-5006CE
32.000000MHz
3.20x2.50x0.90mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004201002600
TG-5006CE
26.000000MHz
3.20x2.50x0.90mm
VC-TCXO~TCXO
2.660to2.940V
Clippedsinewave
X1G004201003200
TG-5006CE
20.000000MHz
3.20x2.50x0.90mm
VC-TCXO~TCXO
3.135to3.465V
Clippedsinewave
X1G004201003300
TG-5006CE
25.000000MHz
3.20x2.50x0.90mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004201006200
TG-5006CE
32.000000MHz
3.20x2.50x0.90mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004211000100
TG-5006CG
26.000000MHz
2.50x2.00x0.80mm
VC-TCXO~TCXO
2.660to2.940V
Clippedsinewave
X1G004211000200
TG-5006CG
26.000000MHz
2.50x2.00x0.80mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004211000300
TG-5006CG
26.000000MHz
2.50x2.00x0.80mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004211000400
TG-5006CG
16.368000MHz
2.50x2.00x0.80mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004211000500
TG-5006CG
26.000000MHz
2.50x2.00x0.80mm
VC-TCXO~TCXO
1.700to1.900V
Clippedsinewave
X1G004211000600
TG-5006CG
16.367667MHz
2.50x2.00x0.80mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004211000800
TG-5006CG
16.369000MHz
2.50x2.00x0.80mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004211001100
TG-5006CG
38.400000MHz
2.50x2.00x0.80mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004211001500
TG-5006CG
16.369000MHz
2.50x2.00x0.80mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004211001600
TG-5006CG
19.200000MHz
2.50x2.00x0.80mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004211002700
TG-5006CG
30.000000MHz
2.50x2.00x0.80mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004211003100
TG-5006CG
24.000000MHz
2.50x2.00x0.80mm
VC-TCXO~TCXO
2.850to3.150V
Clippedsinewave
X1G004211003300
TG-5006CG
49.999800MHz
2.50x2.00x0.80mm
VC-TCXO~TCXO
1.700to3.465V
Clippedsinewave
X1G004211003400
TG-5006CG
26.000000MHz
2.50x2.00x0.80mm
VC-TCXO~TCXO
2.520to3.080V
Clippedsinewave
X1G004211003700
TG-5006CG
24.000000MHz
2.50x2.00x0.80mm
VC-TCXO~TCXO
1.700to3.465V
Clippedsinewave
在細分領域上IC設計業產值突破1萬億大關,達1.21萬億,大增42.4%;IC制造業產值達2.22萬億元,增加22.4%;IC封裝業產值為4354億元,增加15.3%;IC測試業產值為2030億元,增加18.4%.晶圓代工與封測業皆位居全球第一、IC設計業排名世界第二,僅次日產晶振美國.中國臺灣2021年半導體產值突破4萬億元新臺幣,晶圓代工和封測業居全球第一9月14日中國臺灣在SEMICON Taiwan 2022國際半導體展開幕典禮上表示,中國臺灣半導體產業經歷半世紀發展,2021年半導體產值達到4.1萬億新臺幣,年增26.7%.
TG-5006CJ愛普生溫補晶振X1G004131001700,5G無線模塊6G路由器6G模塊晶振
