VWEUALJANF-61.440000,5032壓控有源晶振,泰藝晶振

產品簡介

VWEUALJANF-61.440000,5032壓控有源晶振,泰藝晶振，編碼：VWEUALJANF-61.440000，型號：VW，工作溫度：-40°C ~ 85°C，尺寸：5.0mm*3.2mm，頻率：61.44MHz，精度：±50ppm，電壓：3.3V，電流：30mA，石英晶體振蕩器，壓控晶振，石英晶振，泰藝晶振，貼片晶體，進口晶振，典型的5.0 x 3.2 x 1.25 mm 6焊盤陶瓷SMD封裝，可提供緊密對稱，三態使能/禁用，應用于網絡設備，時鐘鐘表，智能手機，平板電腦，無線局域網，無線電話，智能家具家電，車載設備，工業設備等應用。

產品詳情

VWEUALJANF-61.440000,5032壓控有源晶振,泰藝晶振，參數表

編碼	VWEUALJANF-61.440000
品牌	Taitien
型號	OW
頻率	61.44MHz
精度	±50ppm
電壓	3.3V
電流	30mA
工作溫度	-40°C ~ 85°C
尺寸	5.0mm*3.2mm

VWEUALJANF-61.440000,5032壓控有源晶振,泰藝晶振，尺寸圖

VW.5032

Mfr Part #	Supplier	Series	Type	Frequency	Output	Voltage - Supply	Frequency Stability
VTEUMCJANF-19.440000	Taitien	VT	VCXO	19.44 MHz	CMOS	3.3V	±50ppm
VTEUPCJANF-19.440000	Taitien	VT	VCXO	19.44 MHz	CMOS	3.3V	±50ppm
VTEUPCJANF-35.328000	Taitien	VT	VCXO	35.328 MHz	CMOS	3.3V	±50ppm
VTEUMCJANF-35.328000	Taitien	VT	VCXO	35.328 MHz	CMOS	3.3V	±50ppm
VTEUMCJANF-25.000000	Taitien	VT	VCXO	25 MHz	CMOS	3.3V	±50ppm
VTEUPCJANF-33.333000	Taitien	VT	VCXO	33.333 MHz	CMOS	3.3V	±50ppm
VTEUPLJANF-15.360000	Taitien	VT	VCXO	15.36 MHz	CMOS	3.3V	±50ppm
VTEUMCJANF-27.000000	Taitien	VT	VCXO	27 MHz	CMOS	3.3V	±50ppm
VTEUPCJANF-2.048000	Taitien	VT	VCXO	2.048 MHz	CMOS	3.3V	±50ppm
VTEUMCJANF-4.096000	Taitien	VT	VCXO	4.096 MHz	CMOS	3.3V	±50ppm
VWEUPLJANF-38.400000	Taitien	VW	VCXO	38.4 MHz	CMOS	3.3V	±50ppm
VWEUPCJANF-19.440000	Taitien	VW	VCXO	19.44 MHz	CMOS	3.3V	±50ppm
VTEUBLJANF-31.250000	Taitien	VT	VCXO	31.25 MHz	CMOS	3.3V	±50ppm
VTEUMLJANF-35.328000	Taitien	VT	VCXO	35.328 MHz	CMOS	3.3V	±50ppm
VTEUMCJANF-77.760000	Taitien	VT	VCXO	77.76 MHz	CMOS	3.3V	±50ppm
VTEUPLJANF-61.440000	Taitien	VT	VCXO	61.44 MHz	CMOS	3.3V	±50ppm
VTEUPLJANF-40.960000	Taitien	VT	VCXO	40.96 MHz	CMOS	3.3V	±50ppm
VTEUMLJANF-38.880000	Taitien	VT	VCXO	38.88 MHz	CMOS	3.3V	±50ppm
VTEUMLJANF-2.048000	Taitien	VT	VCXO	2.048 MHz	CMOS	3.3V	±50ppm
VTEUPLJANF-16.384000	Taitien	VT	VCXO	16.384 MHz	CMOS	3.3V	±50ppm
VTEUMLJANF-25.000000	Taitien	VT	VCXO	25 MHz	CMOS	3.3V	±50ppm
VWEUALJANF-30.720000	Taitien	VW	VCXO	30.72 MHz	CMOS	3.3V	±50ppm
VWEUBCJANF-50.000000	Taitien	VW	VCXO	50 MHz	CMOS	3.3V	±50ppm
VWEUALLANF-122.880000	Taitien	VW	VCXO	122.88 MHz	LVPECL	3.3V	±50ppm
VTEUALJANF-30.720000	Taitien	VT	VCXO	30.72 MHz	CMOS	3.3V	±50ppm
VTEUMCJANF-50.000000	Taitien	VT	VCXO	50 MHz	CMOS	3.3V	±50ppm
VTEUMLJANF-10.000000	Taitien	VT	VCXO	10 MHz	CMOS	3.3V	±50ppm
