3225貼片差分晶振,FO3HSCBM48.0-T2,??怂咕д?/h4>
頻率:48 MHz
尺寸:3.2*2.5mm
3225貼片差分晶振,FO3HSCBM48.0-T2,??怂咕д?/span>,編碼:FO3HSCBM48.0-T2,型號:FO3HS,工作溫度:-40°C ~ 85°C,尺寸:3.2*2.5mm,頻率:48 MHz,電壓:3.3V,精度:±50ppm,電流:19mA,輸出方式:HCMOS,晶體振蕩器,美國進口晶振,差分晶體,石英差分晶振,差分輸出振蕩器,FOX石英晶振,HCMOS輸出 穩定性高達20 PPM 溫度范圍寬至-40°C至+125°C 電源電壓:1.0V、1.8V、2.5V、3.3V,可變(1.6V ~ 3.63V2.25V ~ 3.63V),差分晶振常用于高精度的時鐘應用,如通信設備,數據存儲器和精密儀器等。它的優點包括低相位噪聲、低抖動和高頻率穩定性,能夠滿足一些對時鐘信號質量要求較高的應用場景,差分晶振是一種常見的電子元件,可用于許多應用領域。
訂購熱線:0755-27876236
頻率:48 MHz
尺寸:3.2*2.5mm
3225貼片差分晶振,FO3HSCBM48.0-T2,??怂咕д?/span>,編碼:FO3HSCBM48.0-T2,型號:FO3HS,工作溫度:-40°C ~ 85°C,尺寸:3.2*2.5mm,頻率:48 MHz,電壓:3.3V,精度:±50ppm,電流:19mA,輸出方式:HCMOS,晶體振蕩器,美國進口晶振,差分晶體,石英差分晶振,差分輸出振蕩器,FOX石英晶振,HCMOS輸出 穩定性高達20 PPM 溫度范圍寬至-40°C至+125°C 電源電壓:1.0V、1.8V、2.5V、3.3V,可變(1.6V ~ 3.63V2.25V ~ 3.63V),差分晶振常用于高精度的時鐘應用,如通信設備,數據存儲器和精密儀器等。它的優點包括低相位噪聲、低抖動和高頻率穩定性,能夠滿足一些對時鐘信號質量要求較高的應用場景,差分晶振是一種常見的電子元件,可用于許多應用領域。
3225貼片差分晶振,FO3HSCBM48.0-T2,福克斯晶振,參數表
編碼 | FO3HSCBM48.0-T2 |
品牌 | FOX |
型號 | FO3HS |
頻率 | 48MHz |
精度 |
±50ppm |
電流 | 19mA |
電壓 |
3.3V |
輸出方式 |
HCMOS |
工作溫度 | -40°C ~ 85°C |
尺寸 | 3.2mm*2.5mm |
Mfr Part # | 差分有源晶振 | Supplier | Series | Type | Frequency | Output | Voltage - Supply |
FT5HNBPK25.0-T1 | Fox Electronics | Fox Electronics | FOX924 | TCXO | 25 MHz | HCMOS | 3.3V |
FT5HNBPK10.0-T1 | Fox Electronics | Fox Electronics | FOX924 | TCXO | 10 MHz | HCMOS | 3.3V |
FT5HNBPK12.0-T1 | Fox Electronics | Fox Electronics | FOX924 | TCXO | 12 MHz | HCMOS | 3.3V |
FT5HNBPK12.288-T1 | Fox Electronics | Fox Electronics | FOX924 | TCXO | 12.288 MHz | HCMOS | 3.3V |
FT5HNBPK14.7456-T1 | Fox Electronics | Fox Electronics | FOX924 | TCXO | 14.7456 MHz | HCMOS | 3.3V |
FT5HNBPK20.0-T1 | Fox Electronics | Fox Electronics | FOX924 | TCXO | 20 MHz | HCMOS | 3.3V |
FT5HNBPK27.0-T1 | Fox Electronics | Fox Electronics | FOX924 | TCXO | 27 MHz | HCMOS | 3.3V |
FT9CVDPH20.0-T1 | Fox Electronics | Fox Electronics | FOX801_E | VCTCXO | 20 MHz | Clipped Sine Wave | 3V |
FT5CNDPK12.8-T1 | Fox Electronics | Fox Electronics | FOX914 | TCXO | 12.8 MHz | Clipped Sine Wave | 3V |
FT5HNBPK16.0-T1 | Fox Electronics | Fox Electronics | FOX924 | TCXO | 16 MHz | HCMOS | 3.3V |
FO7HSCBM50.0-T1 | Fox Electronics | Fox Electronics | FO7HS | XO (Standard) | 50 MHz | HCMOS | 3.3V |
FO7HSCAE48.0-T1 | Fox Electronics | Fox Electronics | FO7HS | XO (Standard) | 48 MHz | HCMOS | 3.3V |
FT1MNTUM-38.4-T1 | Fox Electronics | Fox Electronics | FT1MN | TCXO | 38.4 MHz | Clipped Sine Wave | 1.68V ~ 3.63V |
FT1MNTUM-26.0-T1 | Fox Electronics | Fox Electronics | FT1MN | TCXO | 26 MHz | Clipped Sine Wave | 1.68V ~ 3.63V |
FT5CNDPK20.0-T1 | Fox Electronics | Fox Electronics | FOX914 | TCXO | 20 MHz | Clipped Sine Wave | 3V |
FT5HNBPK19.44-T1 | Fox Electronics | Fox Electronics | FOX924 | TCXO | 19.44 MHz | HCMOS | 3.3V |
FT9CVDPH10.0-T1 | Fox Electronics | Fox Electronics | FOX801_E | VCTCXO | 10 MHz | Clipped Sine Wave | 3V |
FO3HSCBM48.0-T2 | Fox Electronics | Fox Electronics | FO3HS | XO (Standard) | 48 MHz | HCMOS | 3.3V |
FO7HSCAF30.0-T1 | Fox Electronics | Fox Electronics | FO7HS | XO (Standard) | 30 MHz | HCMOS | 3.3V |
FO7HSCAE33.333-T1 | Fox Electronics | Fox Electronics | FO7HS | XO (Standard) | 33.333 MHz | HCMOS | 3.3V |
FO7HSCAM24.0-T1 | Fox Electronics | Fox Electronics | FO7HS | XO (Standard) | 24 MHz | HCMOS | 3.3V |
FO7HSCBM25.0-T1 | Fox Electronics | Fox Electronics | FO7HS | XO (Standard) | 25 MHz | HCMOS | 3.3V |
FO7HSCAE14.31818-T1 | Fox Electronics | Fox Electronics | FO7HS | XO (Standard) | 14.31818 MHz | HCMOS | 3.3V |
FO7HHAAM16.0-T1 | Fox Electronics | Fox Electronics | FO7HH | XO (Standard) | 16 MHz | HCMOS | 5V |
