高頻低抖動時鐘振蕩器531AC200M000DG專用于時鐘和數據恢復

返回列表 來源:壹兆電子 查看手機網址
掃一掃!高頻低抖動時鐘振蕩器531AC200M000DG專用于時鐘和數據恢復掃一掃!
瀏覽:- 發布日期:2023-05-15 17:38:39【
分享到:

Silicon晶振Si531 XO利用天空解決方案的先進DSPLL®電路提供一個高頻低抖動時鐘晶體振蕩器。Si531晶振小體積7.0x5.0mm六腳貼片晶振,可提供從10到945MHz的任意速率輸出頻率,并選擇頻率到1400MHz。與傳統的XO不同,每個輸出頻率都需要一個不同的晶體,使用一個固定的晶體來提供一個大范圍的輸出頻率。這種有源晶振基于集成電路的方法允許晶體諧振器提供特殊的頻率穩定性和可靠性。此外,DSPLL時鐘合成提供了優越的電源噪聲抑制,簡化了在通信系統中通常發現的噪聲環境中產生低抖動時鐘的任務。基于Si531 IC的XO可在工廠中進行配置,可用于各種用戶規格,包括頻率、電源電壓、輸出格式和溫度穩定性。特定的配置在裝運時被工廠編程,從而消除了與定制振蕩器相關的長交貨時間。高頻低抖動時鐘振蕩器531AC200M000DG專用于時鐘和數據恢復

原廠代碼 品牌 型號 頻率 電壓 頻率穩定度 包裝/封裝
531BB125M000DG Silicon晶振 Si531 125MHz 3.3V ±20ppm 6-SMD, No Lead
531FB200M000DG Silicon晶振 Si531 200MHz 2.5V ±20ppm 6-SMD, No Lead
531FC250M000DG Silicon晶振 Si531 250MHz 2.5V ±7ppm 6-SMD, No Lead
531FB125M000DG Silicon晶振 Si531 125MHz 2.5V ±20ppm 6-SMD, No Lead
531BC000110DG Silicon晶振 Si531 148.35165MHz 3.3V ±7ppm 6-SMD, No Lead
531BC200M000DG Silicon晶振 Si531 200MHz 3.3V ±7ppm 6-SMD, No Lead
531BC250M000DG Silicon晶振 Si531 250MHz 3.3V ±7ppm 6-SMD, No Lead
531BC125M000DG Silicon晶振 Si531 125MHz 3.3V ±7ppm 6-SMD, No Lead
531FB106M250DG Silicon晶振 Si531 106.25MHz 2.5V ±20ppm 6-SMD, No Lead
531AC156M250DG Silicon晶振 Si531 156.25MHz 3.3V ±7ppm 6-SMD, No Lead
531AC200M000DG Silicon晶振 Si531 200MHz 3.3V ±7ppm 6-SMD, No Lead
531BC148M500DG Silicon晶振 Si531 148.5MHz 3.3V ±7ppm 6-SMD, No Lead
531BC156M250DG Silicon晶振 Si531 156.25MHz 3.3V ±7ppm 6-SMD, No Lead
531AC125M000DG Silicon晶振 Si531 125MHz 3.3V ±7ppm 6-SMD, No Lead
531FC125M000DG Silicon晶振 Si531 125MHz 2.5V ±7ppm 6-SMD, No Lead
531FC156M250DG Silicon晶振 Si531 156.25MHz 2.5V ±7ppm 6-SMD, No Lead
531FC148M500DG Silicon晶振 Si531 148.5MHz 2.5V ±7ppm 6-SMD, No Lead
531AC155M520DG Silicon晶振 Si531 155.52MHz 3.3V ±7ppm 6-SMD, No Lead
531BC155M520DG Silicon晶振 Si531 155.52MHz 3.3V ±7ppm 6-SMD, No Lead
531FC200M000DG Silicon晶振 Si531 200MHz 2.5V ±7ppm 6-SMD, No Lead
531AC622M080DG Silicon晶振 Si531 622.08MHz 3.3V ±7ppm 6-SMD, No Lead
531AC312M500DG Silicon晶振 Si531 312.5MHz 3.3V ±7ppm 6-SMD, No Lead
531AC106M250DG Silicon晶振 Si531 106.25MHz 3.3V ±7ppm 6-SMD, No Lead
531EC106M250DG Silicon晶振 Si531 106.25MHz 2.5V ±7ppm 6-SMD, No Lead
531BC187M500DG Silicon晶振 Si531 187.5MHz 3.3V ±7ppm 6-SMD, No Lead
531EC155M520DG Silicon晶振 Si531 155.52MHz 2.5V ±7ppm 6-SMD, No Lead
531AC187M500DG Silicon晶振 Si531 187.5MHz 3.3V ±7ppm 6-SMD, No Lead
531EC187M500DG Silicon晶振 Si531 187.5MHz 2.5V ±7ppm 6-SMD, No Lead
531EC000110DG Silicon晶振 Si531 148.35165MHz 2.5V ±7ppm 6-SMD, No Lead
531EC148M500DG Silicon晶振 Si531 148.5MHz 2.5V ±7ppm 6-SMD, No Lead
531FC155M520DG Silicon晶振 Si531 155.52MHz 2.5V ±7ppm 6-SMD, No Lead
531EC156M250DG Silicon晶振 Si531 156.25MHz 2.5V ±7ppm 6-SMD, No Lead
531AC311M040DG Silicon晶振 Si531 311.04MHz 3.3V ±7ppm 6-SMD, No Lead
531BC311M040DG Silicon晶振 Si531 311.04MHz 3.3V ±7ppm 6-SMD, No Lead
531EC311M040DG Silicon晶振 Si531 311.04MHz 2.5V ±7ppm 6-SMD, No Lead
531EC622M080DG Silicon晶振 Si531 622.08MHz 2.5V ±7ppm 6-SMD, No Lead
531FC622M080DG Silicon晶振 Si531 622.08MHz 2.5V ±7ppm 6-SMD, No Lead
531FC311M040DG Silicon晶振 Si531 311.04MHz 2.5V ±7ppm 6-SMD, No Lead
531BC622M080DG Silicon晶振 Si531 622.08MHz 3.3V ±7ppm 6-SMD, No Lead
531FC312M500DG Silicon晶振 Si531 312.5MHz 2.5V ±7ppm 6-SMD, No Lead
531EC312M500DG Silicon晶振 Si531 312.5MHz 2.5V ±7ppm 6-SMD, No Lead
531AC250M000DG Silicon晶振 Si531 250MHz 3.3V ±7ppm 6-SMD, No Lead
531EC250M000DG Silicon晶振 Si531 250MHz 2.5V ±7ppm 6-SMD, No Lead
531BC312M500DG Silicon晶振 Si531 312.5MHz 3.3V ±7ppm 6-SMD, No Lead
531AA156M250DG Silicon晶振 Si531 156.25MHz 3.3V ±50ppm 6-SMD, No Lead
531BC106M250DG Silicon晶振 Si531 106.25MHz 3.3V ±7ppm 6-SMD, No Lead
531EC125M000DG Silicon晶振 Si531 125MHz 2.5V ±7ppm 6-SMD, No Lead
531FC106M250DG Silicon晶振 Si531 106.25MHz 2.5V ±7ppm 6-SMD, No Lead
531FC187M500DG Silicon晶振 Si531 187.5MHz 2.5V ±7ppm 6-SMD, No Lead
531FC000110DG Silicon晶振 Si531 148.35165MHz 2.5V ±7ppm 6-SMD, No Lead
531EC200M000DG Silicon晶振 Si531 200MHz 2.5V ±7ppm 6-SMD, No Lead
531AC000110DG Silicon晶振 Si531 148.35165MHz 3.3V ±7ppm 6-SMD, No Lead
531AC148M500DG Silicon晶振 Si531 148.5MHz 3.3V ±7ppm 6-SMD, No Lead
531AC125M000DGR Silicon晶振 Si531 125MHz 3.3V ±7ppm 6-SMD, No Lead
531BC125M000DGR Silicon晶振 Si531 125MHz 3.3V ±7ppm 6-SMD, No Lead
531EC125M000DGR Silicon晶振 Si531 125MHz 2.5V ±7ppm 6-SMD, No Lead
531FC125M000DGR Silicon晶振 Si531 125MHz 2.5V ±7ppm 6-SMD, No Lead
531AC106M250DGR Silicon晶振 Si531 106.25MHz 3.3V ±7ppm 6-SMD, No Lead
531BC106M250DGR Silicon晶振 Si531 106.25MHz 3.3V ±7ppm 6-SMD, No Lead
531EC106M250DGR Silicon晶振 Si531 106.25MHz 2.5V ±7ppm 6-SMD, No Lead
531FC106M250DGR Silicon晶振 Si531 106.25MHz 2.5V ±7ppm 6-SMD, No Lead
531FC25M0000DGR Silicon晶振 Si531 25MHz 2.5V ±7ppm 6-SMD, No Lead
531AC155M520DGR Silicon晶振 Si531 155.52MHz 3.3V ±7ppm 6-SMD, No Lead
531AC156M250DGR Silicon晶振 Si531 156.25MHz 3.3V ±7ppm 6-SMD, No Lead
531BC155M520DGR Silicon晶振 Si531 155.52MHz 3.3V ±7ppm 6-SMD, No Lead
531BC156M250DGR Silicon晶振 Si531 156.25MHz 3.3V ±7ppm 6-SMD, No Lead
531EC155M520DGR Silicon晶振 Si531 155.52MHz 2.5V ±7ppm 6-SMD, No Lead
531EC156M250DGR Silicon晶振 Si531 156.25MHz 2.5V ±7ppm 6-SMD, No Lead
531FC155M520DGR Silicon晶振 Si531 155.52MHz 2.5V ±7ppm 6-SMD, No Lead
531FC156M250DGR Silicon晶振 Si531 156.25MHz 2.5V ±7ppm 6-SMD, No Lead
531AC187M500DGR Silicon晶振 Si531 187.5MHz 3.3V ±7ppm 6-SMD, No Lead
531BC187M500DGR Silicon晶振 Si531 187.5MHz 3.3V ±7ppm 6-SMD, No Lead
531EC187M500DGR Silicon晶振 Si531 187.5MHz 2.5V ±7ppm 6-SMD, No Lead
531FC187M500DGR Silicon晶振 Si531 187.5MHz 2.5V ±7ppm 6-SMD, No Lead
531AC000110DGR Silicon晶振 Si531 148.35165MHz 3.3V ±7ppm 6-SMD, No Lead
531AC148M500DGR Silicon晶振 Si531 148.5MHz 3.3V ±7ppm 6-SMD, No Lead
531AC200M000DGR 貼片晶振 Si531 200MHz 3.3V ±7ppm 6-SMD, No Lead
531BC000110DGR Silicon晶振 Si531 148.35165MHz 3.3V ±7ppm 6-SMD, No Lead
531BC148M500DGR Silicon晶振 Si531 148.5MHz 3.3V ±7ppm 6-SMD, No Lead
531BC200M000DGR Silicon晶振 Si531 200MHz 3.3V ±7ppm 6-SMD, No Lead
531EC000110DGR Silicon晶振 Si531 148.35165MHz 2.5V ±7ppm 6-SMD, No Lead
531EC148M500DGR Silicon晶振 Si531 148.5MHz 2.5V ±7ppm 6-SMD, No Lead
531EC200M000DGR Silicon晶振 Si531 200MHz 2.5V ±7ppm 6-SMD, No Lead
531FC000110DGR Silicon晶振 Si531 148.35165MHz 2.5V ±7ppm 6-SMD, No Lead
531FC148M500DGR Silicon晶振 Si531 148.5MHz 2.5V ±7ppm 6-SMD, No Lead
531FC200M000DGR Silicon晶振 Si531 200MHz 2.5V ±7ppm 6-SMD, No Lead
531AC312M500DGR Silicon晶振 Si531 312.5MHz 3.3V ±7ppm 6-SMD, No Lead
531BC312M500DGR Silicon晶振 Si531 312.5MHz 3.3V ±7ppm 6-SMD, No Lead
531EC312M500DGR Silicon晶振 Si531 312.5MHz 2.5V ±7ppm 6-SMD, No Lead
531FC312M500DGR Silicon晶振 Si531 312.5MHz 2.5V ±7ppm 6-SMD, No Lead
531AC250M000DGR Silicon晶振 Si531 250MHz 3.3V ±7ppm 6-SMD, No Lead
531AC311M040DGR Silicon晶振 Si531 311.04MHz 3.3V ±7ppm 6-SMD, No Lead
531AC622M080DGR Silicon晶振 Si531 622.08MHz 3.3V ±7ppm 6-SMD, No Lead
531BC250M000DGR Silicon晶振 Si531 250MHz 3.3V ±7ppm 6-SMD, No Lead
531BC311M040DGR Silicon晶振 Si531 311.04MHz 3.3V ±7ppm 6-SMD, No Lead
531BC622M080DGR Silicon晶振 Si531 622.08MHz 3.3V ±7ppm 6-SMD, No Lead
531EC250M000DGR Silicon晶振 Si531 250MHz 2.5V ±7ppm 6-SMD, No Lead
531EC311M040DGR Silicon晶振 Si531 311.04MHz 2.5V ±7ppm 6-SMD, No Lead
531EC622M080DGR Silicon晶振 Si531 622.08MHz 2.5V ±7ppm 6-SMD, No Lead
531FC250M000DGR Silicon晶振 Si531 250MHz 2.5V ±7ppm 6-SMD, No Lead
531FC311M040DGR Silicon晶振 Si531 311.04MHz 2.5V ±7ppm 6-SMD, No Lead
531FC622M080DGR Silicon晶振 Si531 622.08MHz 2.5V ±7ppm 6-SMD, No Lead
531AA640M000BG Silicon晶振 Si531 640MHz 3.3V ±50ppm 6-SMD, No Lead
高頻低抖動時鐘振蕩器531AC200M000DG專用于時鐘和數據恢復

Si531晶振特征:

可與任意速率的輸出頻率從10 MHz到945MHz和選擇頻率到1.4 GHz

第三代DSPLL®具有優越的抖動性能

比基于saw的振蕩器好3倍的頻率穩定性

內部固定的晶體頻率確保了高可靠性和低老化

可用的CMOS、LVPECL、LVDS和CML輸出石英晶體振蕩器

3.3、2.5和1.8 V的供應選項

工業標準7.0x5.0mm封裝和針形管

無鉛/符合RoHS標準

應用于:超聲波,網絡系統,SD/高清視頻,測試和測量,時鐘和數據恢復,F(xiàn)PGA/ASIC時鐘生成

Si530,Si531
