ECS-2520S25-240-FN-TR,2520有源晶振,ECS貼片晶振
頻率：24MHz
尺寸：2.5mm x 2.0mm
ECS-2520S25-240-FN-TR,2520有源晶振,ECS貼片晶振，型號：ECS-2520S系列晶振，編碼為：ECS-2520S25-240-FN-TR，頻率：24MHz,尺寸：2.5*2.0mm,工作溫度為：﹣40°C ~ 85°C，微型ECS-2520S是微型SMD HCMOS緊密穩定石英晶體振蕩器，2.5 x 2.0 x 0.9毫米陶瓷封裝是理想之選 對于穩定性至關重要無線和IOT應用。
訂購熱線：0755-27876236
ECS-2520S25-240-FN-TR,2520有源晶振,ECS貼片晶振，型號：ECS-2520S系列晶振，編碼為：ECS-2520S25-240-FN-TR，頻率：24MHz,尺寸：2.5*2.0mm,工作溫度為：﹣40°C ~ 85°C，微型ECS-2520S是微型SMD HCMOS緊密穩定石英晶體振蕩器，2.5 x 2.0 x 0.9毫米陶瓷封裝是理想之選 對于穩定性至關重要無線和IOT應用。
| PARAMETERS | CONDITIONS | ECS-2520S | UNITS | ||||||||||||||
| MIN | TYP | MAX | |||||||||||||||
| Frequency Range |
|
|
24 |
|
MHz | ||||||||||||
| Frequency Stability * | EN (-40 ~ +85°C) | ± 15 | ppm | ||||||||||||||
| FN (-40 ~ +85°C) | ± 10 | ppm | |||||||||||||||
| Power Supply | Vdd ±10% | +1.8, +2.5, +3.0, +3.3 | V DC | ||||||||||||||
| Current Consumption | 7 | mA | |||||||||||||||
| Standby Current | 10 | µA | |||||||||||||||
| Output | HCMOS | 15 | pF | ||||||||||||||
| Output voltage Level | VOL:10%Vdd max./VOH:90%Vddmin.V DC | ||||||||||||||||
| Rise & Fall time | 10%Vdd – 90%Vdd | 5 | ns | ||||||||||||||
| Duty Cycle | @ ½ Vdd | 45/55 | % | ||||||||||||||
| Phase Noise | @ 10 KHz offset | -145 | dBc/Hz | ||||||||||||||
| Operating Temp | -40 | +85 | °C | ||||||||||||||
| Storage Temp | -55 | +125 | °C | ||||||||||||||
ECS-2520S25-240-FN-TR,2520有源晶振,ECS貼片晶振，尺寸圖
| Manufacturer Part Number原廠代碼 | OSC石英晶振 | Series型號 | Frequency 頻率 | Operating Temperature 工作溫度 |
| ECS-2520S25-240-FN-TR | ECS 晶振 | ECS-2520S | 24MHz | -40°C ~ 85°C |
| ECS-2520S25-240-FN-TR | ECS 晶振 | ECS-2520S | 24MHz | -40°C ~ 85°C |
| ECS-2520S25-240-FN-TR | ECS 晶振 | ECS-2520S | 24MHz | -40°C ~ 85°C |
| ECS-2520S25-500-FN-TR | ECS 晶振 | ECS-2520S | 50MHz | -40°C ~ 85°C |
| ECS-2520S25-500-FN-TR | ECS 晶振 | ECS-2520S | 50MHz | -40°C ~ 85°C |
| ECS-2520S25-500-FN-TR | ECS 晶振 | ECS-2520S | 50MHz | -40°C ~ 85°C |
| ECS-2520S18-100-FN-TR | ECS 晶振 | ECS-2520S | 10MHz | -40°C ~ 85°C |
| ECS-2520S18-100-FN-TR | ECS 晶振 | ECS-2520S | 10MHz | -40°C ~ 85°C |
| ECS-2520S18-100-FN-TR | ECS 晶振 | ECS-2520S | 10MHz | -40°C ~ 85°C |
| ECS-2520S18-120-FN-TR | ECS 晶振 | ECS-2520S | 12MHz | -40°C ~ 85°C |
| ECS-2520S18-120-FN-TR | ECS 晶振 | ECS-2520S | 12MHz | -40°C ~ 85°C |
| ECS-2520S18-120-FN-TR | ECS 晶振 | ECS-2520S | 12MHz | -40°C ~ 85°C |
| ECS-2520S18-160-FN-TR | ECS 晶振 | ECS-2520S | 16MHz | -40°C ~ 85°C |
| ECS-2520S18-160-FN-TR | ECS 晶振 | ECS-2520S | 16MHz | -40°C ~ 85°C |
| ECS-2520S18-160-FN-TR | ECS 晶振 | ECS-2520S | 16MHz | -40°C ~ 85°C |
| ECS-2520S18-240-FN-TR | ECS 晶振 | ECS-2520S | 24MHz | -40°C ~ 85°C |
| ECS-2520S18-240-FN-TR | ECS 晶振 | ECS-2520S | 24MHz | -40°C ~ 85°C |
| ECS-2520S18-240-FN-TR | ECS 晶振 | ECS-2520S | 24MHz | -40°C ~ 85°C |
| ECS-2520S18-250-FN-TR | ECS 晶振 | ECS-2520S | 25MHz | -40°C ~ 85°C |
| ECS-2520S18-250-FN-TR | ECS 晶振 | ECS-2520S | 25MHz | -40°C ~ 85°C |
| ECS-2520S18-250-FN-TR | ECS 晶振 | ECS-2520S | 25MHz | -40°C ~ 85°C |
| ECS-2520S18-260-FN-TR | ECS 晶振 | ECS-2520S | 26MHz | -40°C ~ 85°C |
| ECS-2520S18-260-FN-TR | ECS 晶振 | ECS-2520S | 26MHz | -40°C ~ 85°C |
| ECS-2520S18-260-FN-TR | ECS 晶振 | ECS-2520S | 26MHz | -40°C ~ 85°C |
| ECS-2520S18-320-FN-TR | ECS 晶振 | ECS-2520S | 32MHz | -40°C ~ 85°C |
| ECS-2520S18-320-FN-TR | ECS 晶振 | ECS-2520S | 32MHz | -40°C ~ 85°C |
| ECS-2520S18-320-FN-TR | ECS 晶振 | ECS-2520S | 32MHz | -40°C ~ 85°C |
| ECS-2520S18-400-FN-TR | ECS 晶振 | ECS-2520S | 40MHz | -40°C ~ 85°C |
| ECS-2520S18-400-FN-TR | ECS 晶振 | ECS-2520S | 40MHz | -40°C ~ 85°C |
| ECS-2520S18-400-FN-TR | ECS 晶振 | ECS-2520S | 40MHz | -40°C ~ 85°C |
| ECS-2520S18-500-FN-TR | ECS 晶振 | ECS-2520S | 50MHz | -40°C ~ 85°C |
深圳市壹兆電子科技有限公司
聯系人：龔成
電話：0755--27876236聯系人：龔成
QQ：769468702
手機：13590198504
郵箱:[email protected]
網站:http://ellentracy.cn
采購：ECS-2520S25-240-FN-TR,2520有源晶振,ECS貼片晶振
- *聯系人：
- *手機：
- 公司名稱：
- 郵箱：
- *采購意向：
-
*驗證碼：
跟此產品相關的產品 / Related Products
- 8W-12.288MBD-T,小體積2520貼片晶振,TXC石英晶體振蕩器
