7050溫補有源晶振,7N-38.880MBP-T,TXC晶體振蕩器
頻率:38.88 MHz
尺寸:7.0mm*5.0mm
7050溫補有源晶振,7N-38.880MBP-T,TXC晶體振蕩器,編碼:7N-38.880MBP-T,型號:7N,工作溫度:-40°C ~ 85°C,尺寸:7.0mm*5.0mm,頻率:38.88 MHz,精度:±280ppb,電壓:3.3V,電流:10mA,臺產晶振,有源7050貼片晶振,高精度溫補晶振,TCXO晶振,頻率范圍: 10MHz至52MHz,SMD接縫密封陶瓷封裝,電源電壓:3.3V,CMOS輸出,電壓控制功能可用,符合RoHS標準& Pb免費,產品廣泛應用于無線通信,基站,網絡設備,軍事設備 ,測試和測量設備,衛星導航。
7050溫補有源晶振,7N-38.880MBP-T,TXC晶體振蕩器,參數表
編碼 |
7N-38.880MBP-T |
品牌 | TXC |
型號 | 7N |
頻率 | 38.88 MHz |
精度 |
±280ppb |
電壓 |
3.3V |
電流 |
10mA |
工作溫度 |
-40°C ~ 85°C |
尺寸 | 7.0mm*5.0mm |
Mfr Part # | TCXO晶振 | Series | Type | Frequency | Output | Voltage - Supply | Frequency Stability |
7N-20.000MBP-T | TXC CORPORATION | 7N | TCXO | 20 MHz | CMOS | 3.3V | ±280ppb |
7N-12.800MBP-T | TXC CORPORATION | 7N | TCXO | 12.8 MHz | CMOS | 3.3V | ±280ppb |
7N-10.000MBP-T | TXC CORPORATION | 7N | TCXO | 10 MHz | CMOS | 3.3V | ±280ppb |
7P-19.200MBP-T | TXC CORPORATION | 7P | TCXO | 19.2 MHz | CMOS | 3.3V | ±280ppb |
7N-19.200MBP-T | TXC CORPORATION | 7N | TCXO | 19.2 MHz | CMOS | 3.3V | ±280ppb |
7N-19.440MBP-T | TXC CORPORATION | 7N | TCXO | 19.44 MHz | CMOS | 3.3V | ±280ppb |
7N48071005 | TXC CORPORATION | 7N | TCXO | 48 MHz | CMOS | 3.3V | ±140ppb |
7N38871002 | TXC CORPORATION | 7N | TCXO | 38.88 MHz | CMOS | 3.3V | ±250ppb |
7N19471005 | TXC CORPORATION | 7N | TCXO | 19.44 MHz | CMOS | 3.3V | ±140ppb |
7N20070004 | TXC CORPORATION | 7N | TCXO | 20 MHz | CMOS | 3.3V | ±250ppb |
7N10071003 | TXC CORPORATION | 7N | TCXO | 10 MHz | CMOS | 3.3V | ±250ppb |
7N20071005 | TXC CORPORATION | 7N | TCXO | 20 MHz | CMOS | 3.3V | ±140ppb |
7N48071001 | TXC CORPORATION | 7N | TCXO | 48 MHz | CMOS | 3.3V | ±250ppb |
7N19471003 | TXC CORPORATION | 7N | TCXO | 19.44 MHz | CMOS | 3.3V | ±250ppb |
7N38871003 | TXC CORPORATION | 7N | TCXO | 38.88 MHz | CMOS | 3.3V | ±140ppb |
7P-25.000MBP-T | TXC CORPORATION | 7P | TCXO | 25 MHz | CMOS | 3.3V | ±280ppb |
7P-26.000MBP-T | TXC CORPORATION | 7P | TCXO | 26 MHz | CMOS | 3.3V | ±280ppb |
7P-38.400MBP-T | TXC CORPORATION | 7P | TCXO | 38.4 MHz | CMOS | 3.3V | ±280ppb |
7N-25.000MBP-T | TXC CORPORATION | 7N | TCXO | 25 MHz | CMOS | 3.3V | ±280ppb |
7N-26.000MBP-T | TXC CORPORATION | 7N | TCXO | 26 MHz | CMOS | 3.3V | ±280ppb |
7N-38.880MBP-T | TXC CORPORATION | 7N | TCXO | 38.88 MHz | CMOS | 3.3V | ±280ppb |
7N-40.000MBP-T | TXC CORPORATION | 7N | TCXO | 40 MHz | CMOS | 3.3V | ±280ppb |
7Q-16.367667MBN-T | TXC CORPORATION | 7Q | TCXO | 16.367667 MHz | Clipped Sine Wave | 3.3V | ±2ppm |
7Q-16.368MBN-T | TXC CORPORATION | 7Q | TCXO | 16.368 MHz | Clipped Sine Wave | 3.3V | ±2ppm |
7Q-19.200MBS-T | TXC CORPORATION | 7Q | VCTCXO | 19.2 MHz | Clipped Sine Wave | 3.3V | ±2ppm |
7Q-26.000MBS-T | TXC CORPORATION | 7Q | VCTCXO | 26 MHz | Clipped Sine Wave | 3.3V | ±2ppm |
7Q-40.000MBS-T | TXC CORPORATION | 7Q | VCTCXO | 40 MHz | Clipped Sine Wave | 3.3V | ±2ppm |
7Q-16.367667MBG-T | TXC CORPORATION | 7Q | TCXO | 16.367667 MHz | Clipped Sine Wave | 3.3V | ±500ppb |
7Q-16.3676MBG-T | TXC CORPORATION | 7Q | TCXO | 16.3676 MHz | Clipped Sine Wave | 3.3V | ±500ppb |
7Q-16.368MBG-T | TXC CORPORATION | 7Q | TCXO | 16.368 MHz | Clipped Sine Wave | 3.3V | ±500ppb |
7Q-16.369MBG-T | TXC CORPORATION | 7Q | TCXO | 16.369 MHz | Clipped Sine Wave | 3.3V | ±500ppb |
7Q-26.000MBG-T | TXC CORPORATION | 7Q | TCXO | 26 MHz | Clipped Sine Wave | 3.3V | ±500ppb |
7Q-12.800MCS-T | TXC CORPORATION | 7Q | VCTCXO | 12.8 MHz | Clipped Sine Wave | 2.5V | ±2ppm |
7Q-16.000MCS-T | TXC CORPORATION | 7Q | VCTCXO | 16 MHz | Clipped Sine Wave | 2.5V | ±2ppm |
7Q-16.3676MCS-T | TXC CORPORATION | 7Q | VCTCXO | 16.3676 MHz | Clipped Sine Wave | 2.5V | ±2ppm |
