8Z-16.000MAHE-T,2520小型貼片晶振,TXC進口石英晶體
頻率:16MHz
尺寸:2.5*2.0mm
8Z-16.000MAHE-T,2520小型貼片晶振,TXC進口石英晶體,編碼:8Z-16.000MAHE-T,型號:8Z,工作溫度:-40C ~ 85°C,尺寸:2.5*2.0mm,頻率:16MHz,精度:±30ppm,負載電容:12pF,石英晶體晶振,晶體諧振器,進口晶振,臺產晶振,石英晶振,貼片石英晶體,貼片無源晶振,頻率范圍:12MHZ至66MHZ,陶瓷SMD封裝,接縫密封,外部尺寸長:2.5 x寬:2.0 x高:0.55 ,符合RoHS標準無鉛,適用于計算機,筆記本電腦,光纖通信,無線電話,時鐘鐘表,智能手機,網絡設備,工業設備。
8Z-16.000MAHE-T,2520小型貼片晶振,TXC進口石英晶體,參數表
編碼 | 8Z-16.000MAHE-T |
品牌 | TXC |
型號 | 8Z |
頻率 | 16MHz |
精度 |
±30ppm |
負載電容 |
12pF |
工作溫度 |
-40C ~ 85°C |
尺寸 | 2.5*2.0mm |
Mfr Part # | 進口晶振2520 | Series | Frequency | Frequency Tolerance | Load Capacitance | Operating Temperature |
8Z-16.000MAHE-T | TXC CORPORATION | 8Z | 16MHz | ±30ppm | 12pF | -40°C ~ 85°C |
8Z-12.000MAAJ-T | TXC CORPORATION | 8Z | 12MHz | ±30ppm | 18pF | -20°C ~ 70°C |
8Z-25.000MAAJ-T | TXC CORPORATION | 8Z | 25MHz | ±30ppm | 18pF | -20°C ~ 70°C |
8Z-27.120MAAV-T | TXC CORPORATION | 8Z | 27.12MHz | ±30ppm | 8pF | -20°C ~ 70°C |
8Z-12.000MAHQ-T | TXC CORPORATION | 8Z | 12MHz | ±30ppm | 10pF | -40°C ~ 85°C |
8Z-12.000MAHE-T | TXC CORPORATION | 8Z | 12MHz | ±30ppm | 12pF | -40°C ~ 85°C |
8Z-24.000MAAJ-T | TXC CORPORATION | 8Z | 24MHz | ±30ppm | 18pF | -20°C ~ 70°C |
8Z-16.000MAAJ-T | TXC CORPORATION | 8Z | 16MHz | ±30ppm | 18pF | -20°C ~ 70°C |
8Z-26.000MEEQ-T | TXC CORPORATION | 8Z | 26MHz | ±10ppm | 10pF | -20°C ~ 70°C |
8Z-25.000MEEQ-T | TXC CORPORATION | 8Z | 25MHz | ±10ppm | 10pF | -20°C ~ 70°C |
8Z-24.000MAAV-T | TXC CORPORATION | 8Z | 24MHz | ±30ppm | 8pF | -20°C ~ 70°C |
8Z-16.000MAAV-T | TXC CORPORATION | 8Z | 16MHz | ±30ppm | 8pF | -20°C ~ 70°C |
8Z-18.432MAHE-T | TXC CORPORATION | 8Z | 18.432MHz | ±30ppm | 12pF | -40°C ~ 85°C |
8Z-19.200MEEQ-T | TXC CORPORATION | 8Z | 19.2MHz | ±10ppm | 10pF | -20°C ~ 70°C |
8Z-16.000MEEQ-T | TXC CORPORATION | 8Z | 16MHz | ±10ppm | 10pF | -20°C ~ 70°C |
8Z-27.120MEEQ-T | TXC CORPORATION | 8Z | 27.12MHz | ±10ppm | 10pF | -20°C ~ 70°C |
8Z-16.66667MAAE-T | TXC CORPORATION | 8Z | 16.66667MHz | ±30ppm | 12pF | -20°C ~ 70°C |
8Z-38.400MAAE-T | TXC CORPORATION | 8Z | 38.4MHz | ±30ppm | 12pF | -20°C ~ 70°C |
8Z-27.120MAHQ-T | TXC CORPORATION | 8Z | 27.12MHz | ±30ppm | 10pF | -40°C ~ 85°C |
8Z-24.000MAHQ-T | TXC CORPORATION | 8Z | 24MHz | ±30ppm | 10pF | -40°C ~ 85°C |
8Z-24.000MAHE-T | TXC CORPORATION | 8Z | 24MHz | ±30ppm | 12pF | -40°C ~ 85°C |
8Z-19.200MAHE-T | TXC CORPORATION | 8Z | 19.2MHz | ±30ppm | 12pF | -40°C ~ 85°C |
8Z-20.000MAAJ-T | TXC CORPORATION | 8Z | 20MHz | ±30ppm | 18pF | -20°C ~ 70°C |
8Z-14.31818MAAJ-T | TXC CORPORATION | 8Z | 14.31818MHz | ±30ppm | 18pF | -20°C ~ 70°C |
8Z-24.576MAAJ-T | TXC CORPORATION | 8Z | 24.576MHz | ±30ppm | 18pF | -20°C ~ 70°C |
8Z-25.000MAHQ-T | TXC CORPORATION | 8Z | 25MHz | ±30ppm | 10pF | -40°C ~ 85°C |
8Z-24.000MAKV-T | TXC CORPORATION | 8Z | 24MHz | ±30ppm | 8pF | -40°C ~ 125°C |
8Z-27.120MAAJ-T | TXC CORPORATION | 8Z | 27.12MHz | ±30ppm | 18pF | -20°C ~ 70°C |
8Z-31.250MAAJ-T | TXC CORPORATION | 8Z | 31.25MHz | ±30ppm | 18pF | -20°C ~ 70°C |
8Z-37.400MAAJ-T | TXC CORPORATION | 8Z | 37.4MHz | ±30ppm | 18pF | -20°C ~ 70°C |
