TXC CORPORATION
TXC CORPORATION
臺灣TXC晶振是一家領先的專業頻率控制產品制造商,致力于雙列直插式封裝（DIP）和表面貼裝器件（SMD）石英晶體和振蕩器產品的研究、設計、制造和銷售.
TXC 晶技晶振目前專注于以下類別的TXC晶振產品：
晶體（32.768KHz、基本 MHz、高精度 MHz、汽車級）
振蕩器（32.768KHz、CMOS、硅 MEMS、差分輸出、SAW、汽車級）
VCXO（CMOS、差分輸出）
TCXO（基本、GPS、精密）
OCXO (CMOS)臺灣TXC晶振,晶技石英晶振,TXC CORPORATION
TXC CORPORATION
is a leading professional frequency control product manufacturer devoted to the research, design, manufacture, and sale of Dual-Inline-Package (DIP) and Surface Mount Device (SMD) quartz crystal and oscillator products.
TXC currently specializes in these TXC晶體categories of products:
Crystals (32.768KHz, Basic MHz, High Accuracy MHz, Automotive Grade)
Oscillators (32.768KHz, CMOS, Silicon MEMS, Differential Output, SAW, Automotive Grade)
VCXO (CMOS, Differential Output)
TCXO (Basic, GPS, Precision)
OCXO (CMOS)臺灣TXC晶振,晶技石英晶振,TXC CORPORATION
| TXC晶振料號編碼 | 制造商 | 系列 | 晶振頻率 | 頻率容差 | 負載電容 | 工作溫度 | 腳位 | 尺寸 | 描述 |
| 7M-12.000MAAJ-T | TXC | 7M | 12 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 12.0000MHZ 18PF SMD |
| 7M-24.000MAAJ-T | TXC | 7M | 24 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 24.0000MHZ 18PF SMD |
| 7M-25.000MAAJ-T | TXC | 7M | 25 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 25.0000MHZ 18PF SMD |
| 7M-10.000MAHE-T | TXC | 7M | 10 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 10.0000MHZ 12PF SMD |
| 7M-27.000MAAJ-T | TXC | 7M | 27 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 27.0000MHZ 18PF SMD |
| 7M-25.000MEEQ-T | TXC | 7M | 25 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 25.0000MHZ 10PF SMD |
| 7M-27.120MEEQ-T | TXC | 7M | 27.12 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 27.1200MHZ 10PF SMD |
| 7M-27.000MEEQ-T | TXC | 7M | 27 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 27.0000MHZ 10PF SMD |
| 7M-24.000MEEQ-T | TXC | 7M | 24 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 24.0000MHZ 10PF SMD |
| 7M-12.000MEEQ-T | TXC | 7M | 12 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 12.0000MHZ 10PF SMD |
| 7M-16.384MEEQ-T | TXC | 7M | 16.384 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 16.3840MHZ 10PF SMD |
| 7M-16.000MAAE-T | TXC | 7M | 16 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 16.0000MHZ 12PF SMD |
| 7M-12.000MAAE-T | TXC | 7M | 12 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 12.0000MHZ 12PF SMD |
| 7M-50.000MAHV-T | TXC | 7M | 50 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 50.0000MHZ 8PF SMD |
| 7M-25.000MAHV-T | TXC | 7M | 25 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 25.0000MHZ 8PF SMD |
| 7M-16.000MAAJ-T | TXC | 7M | 16 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 16.0000MHZ 18PF SMD |
| 7M-27.120MAAJ-T | TXC | 7M | 27.12 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 27.1200MHZ 18PF SMD |
| 7M-10.000MAAJ-T | TXC | 7M | 10 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 10.0000MHZ 18PF SMD |
| 7M-16.000MAHE-T | TXC | 7M | 16 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 16.0000MHZ 12PF SMD |
| 7M-12.000MAHE-T | TXC | 7M | 12 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 12.0000MHZ 12PF SMD |
| 7M-48.000MAAJ-T | TXC | 7M | 48 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 48.0000MHZ 18PF SMD |
| 7M-16.000MEEQ-T | TXC | 7M | 16 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 16.0000MHZ 10PF SMD |
| 7M-26.000MEEQ-T | TXC | 7M | 26 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 26.0000MHZ 10PF SMD |
| 7M-30.000MEEQ-T | TXC | 7M | 30 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 30.0000MHZ 10PF SMD |
| 7M54072001 | TXC | 7M | 54 MHz | ±20ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 54.0000MHZ 8PF SMD |
| 7M48072001 | TXC | 7M | 48 MHz | ±20ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 48.0000MHZ 8PF SMD |
| 7M50072001 | TXC | 7M | 50 MHz | ±7ppm | 9pF | -40°C ~ 105°C | 4 | 3225 | CRYSTAL 50.0000MHZ 9PF SMD |
| 7M-30.000MAAE-T | TXC | 7M | 30 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 30.0000MHZ 12PF SMD |
| 7M-24.000MAAE-T | TXC | 7M | 24 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 24.0000MHZ 12PF SMD |
| 7M-26.000MAAE-T | TXC | 7M | 26 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 26.0000MHZ 12PF SMD |
| 7M-27.000MAAE-T | TXC | 7M | 27 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 27.0000MHZ 12PF SMD |
| 7M-32.000MAAE-T | TXC | 7M | 32 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 32.0000MHZ 12PF SMD |
| 7M-48.000MAHV-T | TXC | 7M | 48 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 48.0000MHZ 8PF SMD |
| 7M-27.120MAHV-T | TXC | 7M | 27.12 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 27.1200MHZ 8PF SMD |
| 7M-26.000MAAJ-T | TXC | 7M | 26 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 26.0000MHZ 18PF SMD |
| 7M-32.000MAHE-T | TXC | 7M | 32 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 32.0000MHZ 12PF SMD |
| 7M-20.000MAAJ-T | TXC | 7M | 20 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 20.0000MHZ 18PF SMD |
| 7M-27.120MAHE-T | TXC | 7M | 27.12 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 27.1200MHZ 12PF SMD |
| 7M-36.000MAAJ-T | TXC | 7M | 36 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 36.0000MHZ 18PF SMD |
| 7M-13.560MAAJ-T | TXC | 7M | 13.56 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 13.5600MHZ 18PF SMD |
| 7M-20.000MAHE-T | TXC | 7M | 20 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 20.0000MHZ 12PF SMD |
| 7M-32.000MEEQ-T | TXC | 7M | 32 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 32.0000MHZ 10PF SMD |
| 7M-38.400MEEQ-T | TXC | 7M | 38.4 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 38.4000MHZ 10PF SMD |
| 7M54072002貼片晶振 | TXC | 7M | 54 MHz | ±12ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 54.0000MHZ 8PF SMD |
| 7M-48.000MEEQ-T | TXC | 7M | 48 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 48.0000MHZ 10PF SMD |
| 7M-13.560MAAE-T | TXC | 7M | 13.56 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 13.5600MHZ 12PF SMD |
| 7M-50.000MAAE-T | TXC | 7M | 50 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 50.0000MHZ 12PF SMD |
| 7M-30.000MAHV-T | TXC | 7M | 30 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 30.0000MHZ 8PF SMD |
| 7M40070041 | TXC | 7M | 40 MHz | ±20ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 40MHZ 12PF SMD |
| 7M-28.63636MAHE-T | TXC | 7M | 28.63636 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 28.63636MHZ 12PF SMD |
| 7M48072002 | TXC | 7M | 48 MHz | ±10ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 48.0000MHZ 8PF SMD |
| 7M-27.000MAHV-T | TXC | 7M | 27 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 27.0000MHZ 8PF SMD |
| 7M13500011 | TXC | 7M | 13.56 MHz | ±20ppm | 16pF | -20°C ~ 75°C | 4 | 3225 | CRYSTAL 13.5600MHZ 16PF SMD |
| 7M-25.000MAHE-T | TXC | 7M | 25 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 25.0000MHZ 12PF SMD |
| 7M-25.000MAAE-T | TXC | 7M | 25 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 25.0000MHZ 12PF SMD |
| 7M-20.000MBBK-T | TXC | 7M | 20 MHz | ±50ppm | 20pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 20.0000MHZ 20PF SMD |
| 7M-31.250MAAE-T | TXC | 7M | 31.25 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 31.2500MHZ 12PF SMD |
| 7M-28.63636MAAE-T | TXC | 7M | 28.63636 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 28.63636MHZ 12PF SMD |
| 7M-27.120MAAE-T | TXC | 7M | 27.12 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 27.1200MHZ 12PF SMD |
| 7M-41.000MAAE-T | TXC | 7M | 41 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 41.0000MHZ 12PF SMD |
| 7M-24.000MAHV-T | TXC | 7M | 24 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 24.0000MHZ 8PF SMD |
| 7M-10.000MAHV-T | TXC | 7M | 10 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 10.0000MHZ 8PF SMD |
| 7M-32.000MAHV-T | TXC | 7M | 32 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 32.0000MHZ 8PF SMD |
| 7M-16.000MAHV-T | TXC | 7M | 16 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 16.0000MHZ 8PF SMD |
| 7M-19.200MAHV-T | TXC | 7M | 19.2 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 19.2000MHZ 8PF SMD |
| 7M-12.000MAHV-T | TXC | 7M | 12 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 12.0000MHZ 8PF SMD |
| 7M-40.000MAHV-T | TXC | 7M | 40 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 40.0000MHZ 8PF SMD |
| 7M-20.000MAHV-T | TXC | 7M | 20 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 20.0000MHZ 8PF SMD |
| 7M50070032 | TXC | 7M | 50 MHz | ±10ppm | 18pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 50MHZ 18PF SMD |
| 7M-25.000MAKV-T | TXC | 7M | 25 MHz | ±30ppm | 8pF | -40°C ~ 125°C | 4 | 3225 | CRYSTAL 25.0000MHZ 8PF SMD |
| 7M-26.000MAKV-T | TXC | 7M | 26 MHz | ±30ppm | 8pF | -40°C ~ 125°C | 4 | 3225 | CRYSTAL 26.0000MHZ 8PF SMD |
| 7M-40.000MAKV-T | TXC | 7M | 40 MHz | ±30ppm | 8pF | -40°C ~ 125°C | 4 | 3225 | CRYSTAL 40.0000MHZ 8PF SMD |
| 7M-19.200MAAE-T | TXC | 7M | 19.2 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 19.2000MHZ 12PF SMD |
| 7M-26.000MAHE-T | TXC | 7M | 26 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 26.0000MHZ 12PF SMD |
| 7M-12.288MAAJ-T | TXC | 7M | 12.288 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 12.2880MHZ 18PF SMD |
| 7M-27.000MAHE-T | TXC | 7M | 27 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 27.0000MHZ 12PF SMD |
| 7M-40.000MAAJ-T | TXC | 7M | 40 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 40.0000MHZ 18PF SMD |
| 7M-37.400MEEJ-T | TXC | 7M | 37.4 MHz | ±10ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 37.4000MHZ 18PF SMD |
| 7M-50.000MAAJ-T | TXC | 7M | 50 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 50.0000MHZ 18PF SMD |
| 7M50070021 | TXC | 7M | 50 MHz | ±15ppm | 10pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 50.0000MHZ 10PF SMD |
| 7M38872001 | TXC | 7M | 38.88 MHz | ±7ppm | 9pF | -40°C ~ 105°C | 4 | 3225 | CRYSTAL 38.8800MHZ 9PF SMD |
| 7M25072001 | TXC | 7M | 25 MHz | ±7ppm | 9pF | -40°C ~ 105°C | 4 | 3225 | CRYSTAL 25.0000MHZ 9PF SMD |
| 7M-40.000MEEQ-T | TXC | 7M | 40 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 40.0000MHZ 10PF SMD |
| 7M-12.288MEEQ-T | TXC | 7M | 12.288 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 12.2880MHZ 10PF SMD |
| 7M-13.560MEEQ-T | TXC | 7M | 13.56 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 13.5600MHZ 10PF SMD |
| 7M-19.200MEEQ-T | TXC | 7M | 19.2 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 19.2000MHZ 10PF SMD |
| 7M-114.285MCFJ-T | TXC | 7M | 114.285 MHz | ±100ppm | 18pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 114.2850MHZ 18PF SMD |
| 7M-12.288MAAE-T | TXC | 7M | 12.288 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 12.2880MHZ 12PF SMD |
| 7M-10.000MAAE-T | TXC | 7M | 10 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 10.0000MHZ 12PF SMD |
| 7M-26.000MAHV-T | TXC | 7M | 26 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 26.0000MHZ 8PF SMD |
| 7M-24.000MAHE-T | TXC | 7M | 24 MHz | ±30ppm | 12pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 24.0000MHZ 12PF SMD |
| 7M-24.576MAAJ-T | TXC | 7M | 24.576 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 24.5760MHZ 18PF SMD |
| 7M-14.31818MAAJ-T | TXC | 7M | 14.31818 MHz | ±30ppm | 18pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 14.31818MHZ 18PF SMD |
| 7M30772001 | TXC | 7M | 30.72 MHz | ±7ppm | 9pF | -40°C ~ 105°C | 4 | 3225 | CRYSTAL 30.7200MHZ 9PF SMD |
| 7M-22.000MEEQ-T | TXC | 7M | 22 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 22.0000MHZ 10PF SMD |
| 7M-18.432MEEQ-T | TXC | 7M | 18.432 MHz | ±10ppm | 10pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 18.4320MHZ 10PF SMD |
| 7M-38.400MAHV-T | TXC | 7M | 38.4 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 38.4000MHZ 8PF SMD |
| 7M-20.000MAAE-T | TXC | 7M | 20 MHz | ±30ppm | 12pF | -20°C ~ 70°C | 4 | 3225 | CRYSTAL 20.0000MHZ 12PF SMD |
| 7M-12.288MAHV-T | TXC | 7M | 12.288 MHz | ±30ppm | 8pF | -40°C ~ 85°C | 4 | 3225 | CRYSTAL 12.2880MHZ 8PF SMD |
