FCX1M04210512E3J,1612石英晶體諧振器,富士晶振
頻率:32.768K
尺寸:1.6mm*1.0mm
FCX1M04210512E3J,1612石英晶體諧振器,富士晶振,編碼:FCX1M04210512E3J,型號:FCX-1M,工作溫度:﹣20℃ ~ 70℃,尺寸:1.6*1.2mm,頻率:42.105 MHz,精度:±20ppm,負載電容:12pF,無源晶振,日本富士晶體晶振,貼片石英晶振1612,貼片石英晶體,小型,超薄型,具備強防焊裂性,石英晶體在極端嚴酷的環境條件下也能發揮穩定的起振特性,產品本身具有耐熱,耐振,耐撞擊等優良的耐環境特性,滿足無鉛焊接以及高溫回流溫度曲線要求,被廣泛應用于無線電話,GPS,無線通信,平板電腦,時鐘鐘表。
FCX1M04210512E3J,1612石英晶體諧振器,富士晶振,參數表
編碼
FCX1M04210512E3J
品牌
Fuji
型號
FCX-1M
頻率
42.105 MHz
精度
±20ppm
負載電容
12pF
工作溫度
-20°C ~ 70°C
尺寸
1.6mm*1.2mm
Mfr Part # | 富士晶振 | Series | Frequency | Frequency Tolerance | Load Capacitance | Operating Temperature |
FCX3G01474518Y3J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 14.7456 MHz | ±20ppm | 18pF | -40°C ~ 85°C |
FCX3G03300010P5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 33 MHz | ±30ppm | 10pF | -10°C ~ 60°C |
FCX3G03300018Y3J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 33 MHz | ±20ppm | 18pF | -40°C ~ 85°C |
FCX3G01431810Y3J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 14.31818 MHz | ±20ppm | 10pF | -40°C ~ 85°C |
FCX3G04000010P5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 40 MHz | ±30ppm | 10pF | -10°C ~ 60°C |
FCX3G03300010E5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 33 MHz | ±30ppm | 10pF | -20°C ~ 70°C |
FCX3G01431818Y3J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 14.31818 MHz | ±20ppm | 18pF | -40°C ~ 85°C |
FCX3G01474510P5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 14.7456 MHz | ±30ppm | 10pF | -10°C ~ 60°C |
FCX3G02000010P5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 20 MHz | ±30ppm | 10pF | -10°C ~ 60°C |
FCX3G02400012E5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 24 MHz | ±30ppm | 12pF | -20°C ~ 70°C |
FCX3G02457610E5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 24.576 MHz | ±30ppm | 10pF | -20°C ~ 70°C |
FCX3G02450018Y5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 24.5 MHz | ±30ppm | 18pF | -40°C ~ 85°C |
FCX3G01966010E5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 19.6608 MHz | ±30ppm | 10pF | -20°C ~ 70°C |
FCX3G01966018Y3J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 19.6608 MHz | ±20ppm | 18pF | -40°C ~ 85°C |
FCX3G02211818Y3J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 22.1184 MHz | ±20ppm | 18pF | -40°C ~ 85°C |
FCX3G02500010P5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 25 MHz | ±30ppm | 10pF | -10°C ~ 60°C |
FCX3G02457610P5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 24.576 MHz | ±30ppm | 10pF | -10°C ~ 60°C |
FCX3G02211810E5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 22.1184 MHz | ±30ppm | 10pF | -20°C ~ 70°C |
FCX3G02400018Y3J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 24 MHz | ±20ppm | 18pF | -40°C ~ 85°C |
FCX3G02000010E5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 20 MHz | ±30ppm | 10pF | -20°C ~ 70°C |
FCX3G02400010P5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 24 MHz | ±30ppm | 10pF | -10°C ~ 60°C |
FCX3G01966010P5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 19.6608 MHz | ±30ppm | 10pF | -10°C ~ 60°C |
FCX1M04210512E3J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-1M | 42.105 MHz | ±20ppm | 12pF | -20°C ~ 70°C |
FCX1M04400012E3J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-1M | 44 MHz | ±20ppm | 12pF | -20°C ~ 70°C |
FCX3G01638410P5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 16.384 MHz | ±30ppm | 10pF | -10°C ~ 60°C |
FCX3G01200018Y3J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 12 MHz | ±20ppm | 18pF | -40°C ~ 85°C |
FCX3G03000010E5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 30 MHz | ±30ppm | 10pF | -20°C ~ 70°C |
FCX3G01356010E5J | Fuji Crystal (Hong Kong) Electronics Co., Limited | FCX-3G | 13.56 MHz | ±30ppm | 10pF | -20°C ~ 70°C |
聯系人:龔成
QQ:769468702
手機:13590198504
郵箱:[email protected]
網站:http://ellentracy.cn
采購:FCX1M04210512E3J,1612石英晶體諧振器,富士晶振
- *聯系人:
- *手機:
- 公司名稱:
- 郵箱:
- *采購意向:
- *驗證碼:
