X1G005221003600能夠輕易識別網絡信號以及精確的處理雙極信號

Product Number	Model	Frequency	愛普生差分晶振	Output Wave	Supply Voltage
X1G005221000100	SG3225EEN	100.000000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221000200	SG3225EEN	125.000000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221000300	SG3225EEN	125.003125 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221000400	SG3225EEN	155.520000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221000500	SG3225EEN	156.250000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221000700	SG3225EEN	156.253906 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221000800	SG3225EEN	156.250000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221001300	SG3225EEN	100.000000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221001400	SG3225EEN	200.000000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221001800	SG3225EEN	100.000000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221001900	SG3225EEN	50.000000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221002100	SG3225EEN	125.000000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221002300	SG3225EEN	25.000000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221002400	SG3225EEN	166.015625 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221002800	SG3225EEN	156.250000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221003000	SG3225EEN	25.000000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221003100	SG3225EEN	50.000000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221003200	SG3225EEN	160.000000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221003300	SG3225EEN	200.000000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221003400	SG3225EEN	125.000000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V
X1G005221003600	SG3225EEN	54.000000 MHz	3.20 x 2.50 x 1.20 mm	LV-PECL	3.135 to 3.465 V

差分晶振一般為六腳貼片晶振，工作溫度范圍-40℃~+85℃，差分晶振的頻率相對都比較高，比如從50MHz起可以做到700MHz或者更低和更高頻率，且任意頻率精確到個位小數點后六位。電源電壓能夠做到2.5V-3.3V之間。例如：2.25V、2.5V 、3.0V、3.3V、3.6V 可任意選擇應用。常見的封裝尺寸有7050(7.0*5.0mm)、5032(5.0*3.2mm)、3225(3.2*2.5mm)，更小封裝可達到2520(2.5*2.0mm)，常用的輸出方式主要有LVPECL和LVDS差分有源晶振兩種。
